Product Configuration

Controller: Four segment electronic control

Fan: Dual speed fan

Water tank: Oxygen free copper water tank

Fire exhaust: Four season fire exhaust,not afraid of cold in winter and hot in summer

Water sensor: JR-A569

Power word: Standard configuration

Technical Specifications

Applicable gas sources: natural gas (12T)/liquefied gas (20Y)

Rated gas pressure: 200Pa/2800Pa

Rated heat load: 25Kw/30kW

Rated hot water production capacity: 13kg/min/16kg/min at+25C

Applicable water pressure: 0.025-0.8MPa

Rated voltage: AC 220V,50Hz

Rated electrical power: 35w

Body size: 570*380*160MM

Packaging size: 730*510*240MM
